Motor: 230V~,50Hz,1000W
Packing size: 720x650x410mm & 350x270x 380mm
Weight: 51kg / 62kg

Planer

Table size: 600x 150mm
Cutting depth: 0~2.5mm
No. of blade: 2
Blade size: 150x17x 3mm
Cutting speed: 6500rpm

Thicknesser

Table size: 295x150mm
Max cutting height: 100mm
Max cutting depth: 2.5mm
Feeding speed: 7m /min
Cutting speed: 6500rpm

Table saw

Table size: 600x 400mm
Blade size: 160x20mm
Max cutting depth: 55mm
Cutting speed: 4000rpm



Spindle Moulder

Table size: 600x 400mm
Spindle size: 20mm
Spindle travel: 40mm
Spindle speed: 7000rpm
Max cutter dia.: 50mm

Morticer

Table size: 240x 140mm
Max drilling dia.: 13mmLH
Max drilling depth: 40mm
Left/right travel: 90mm
Vertical travel: 30mm

Sliding Panel

Sliding panel size: 655x 120mm
Sliding travel: 420mm
Fence size: 500x 100mm
Fence tilt: 45 °
Dust outlet size : 50mm



Six Function:

l Planer mode
l Mortising mode
l Thicknesser mode
l Spindle moulder mode
l Sliding panel carriage
l Table saw mode w/315 mm main blade Without scoring blade





   110v~,60Hz, 220V,3~, 60Hz motor availabl e
