Aluminium Double Sliding Cutting Saw-CNC

Model: DSCS500x4200-CNC

Motor: 380V, 3~,50Hz,5900W

Blade size: 500x30 mm
Blade speed: 2840 rpm
Max cutting size: 135x300mm
Cutting angle: 90degree, 67.5degree, 45degree
Packing size: 5900x1500x1600 mm
N.W.: 2200 kg

Features:

The machine uses imported blades and imported linear bearings. The main bearing is high precision and makes the blade rotate stably. Liquid damping cylinder realizes uniform,smooth motion.

CNC precision saw system adopts Delta of Taiwan, Mitsubishi of Japan, Omron and other imported system, and realizes automatic feed of automatic cutting, automatic opening and closing protective cover.

CNC saw transmission parts replaces the original way of driving belt step by step with precision ball screw drive (Taiwan ABBA, South Korea imported screw, etc.), thus ensuring the accuracy of cutting length. Repeat positioning is accurate.

Cutting angular error of the section ± 5 . It is the mainstream products of domestic large sized doors and windows.
