Metal Cutting Bandsaw-Gear driving Model

Motor:  230V,50Hz~, 1100W 4poles
400V,50Hz,3~, 1100W, 4poles
Blade size:  2360x20x0.9mm
Blade speed: 67/39/55m/min
Cutting angle: 0~45 degrees(Swivel vice)
Coolant pump: 230V,50Hz~,25W;  400V, 50Hz, 3~, 25W
Packing size 1280x460x1120mm
Weight : 170/190kg


Worn gear box has hardened & ground gears
Miter Cutting Ability
Blade Wheels have Heavy-duty Ball Bearings
Built-in coolant system use water soluble oil
