Motor 1100W
Chuck Capacity 16mm
Max Drill Capacity 25 mm
Spindle Travel 100mm
Spindle Taper MT3
Column Diameter 80mm
Spindle Speed 12(250-2600)rpm
Distance /Chuck to Column 215mm
Table Size 330x330 mm
Base Size 560x340 mm
Packing Size 1335x555x310mm
Weight  102/98Kg

Optional:Cast iron feed handle
Optional: Key-less chuck
Optional:Built-in light
Optional:Tool holder
Optional:Coolant system
Optional:Aluminum pulley & time belt
Optional:Aluminum motor housing
Optional:Left & right running(3 phase motor only)
